1.
ELECTRONICS AND COMMUNICATION ENGINEERING – EC
|
Engineering Mathematics
|
|
Linear Algebra: Matrix Algebra, Systems of linear equations, Eigen values
and eigen vectors.
Calculus: Mean value theorems, Theorems of integral calculus, Evaluation of definite and improper integrals, Partial Derivatives, Maxima and minima, Multiple integrals, Fourier series. Vector identities, Directional derivatives, Line, Surface and Volume integrals, Stokes, Gauss and Green's theorems. Differential equations: First order equation (linear and nonlinear), Higher order linear differential equations with constant coefficients, Method of variation of parameters, Cauchy's and Euler's equations, Initial and boundary value problems, Partial Differential Equations and variable separable method. Complex variables: Analytic functions, Cauchy's integral theorem and integral formula, Taylor's and Laurent' series, Residue theorem, solution integrals. Probability and Statistics: Sampling theorems, Conditional probability, Mean, median, mode and standard deviation, Random variables, Discrete and continuous distributions, Poisson, Normal and Binomial distribution, Correlation and regression analysis. Numerical Methods: Solutions of non-linear algebraic equations, single and multi-step methods for differential equations. Transform Theory: Fourier transform, Laplace transform, Z-transform. |
|
GENERAL APTITUDE(GA):
|
Verbal Ability: English grammar, sentence completion, verbal analogies,
word groups, instructions, critical reasoning and verbal deduction.
|
|
Electronics and
Communication Engineering
|
Networks: Network graphs: matrices associated with graphs;
incidence, fundamental cut set and fundamental circuit matrices. Solution
methods: nodal and mesh analysis. Network theorems: superposition, Thevenin
and Norton's maximum power transfer, Wye-Delta transformation. Steady state
sinusoidal analysis using phasors. Linear constant coefficient differential
equations; time domain analysis of simple RLC circuits, Solution of network
equations using Laplace transform: frequency domain analysis of RLC circuits.
2-port network parameters: driving point and transfer functions. State
equations for networks.
Electronic Devices: Energy bands in silicon, intrinsic and extrinsic silicon. Carrier transport in silicon: diffusion current, drift current, mobility, and resistivity. Generation and recombination of carriers. p-n junction diode, Zener diode, tunnel diode, BJT, JFET, MOS capacitor, MOSFET, LED, p-I-n and avalanche photo diode, Basics of LASERs. Device technology: integrated circuits fabrication process, oxidation, diffusion, ion implantation, photolithography, n-tub, p-tub and twin-tub CMOS process. Analog Circuits: Small Signal Equivalent circuits of diodes, BJTs, MOSFETs and analog CMOS. Simple diode circuits, clipping, clamping, rectifier. Biasing and bias stability of transistor and FET amplifiers. Amplifiers: single-and multi-stage, differential and operational, feedback, and power. Frequency response of amplifiers. Simple op-amp circuits. Filters. Sinusoidal oscillators; criterion for oscillation; single-transistor and op-amp configurations. Function generators and wave-shaping circuits, 555 Timers. Power supplies. Digital circuits: Boolean algebra, minimization of Boolean functions; logic gates; digital IC families (DTL, TTL, ECL, MOS, CMOS). Combinatorial circuits: arithmetic circuits, code converters, multiplexers, decoders, PROMs and PLAs. Sequential circuits: latches and flip-flops, counters and shift-registers. Sample and hold circuits, ADCs, DACs. Semiconductor memories. Microprocessor(8085): architecture, programming, memory and I/O interfacing. Signals and Systems: Definitions and properties of Laplace transform, continuous-time and discrete-time Fourier series, continuous-time and discrete-time Fourier Transform, DFT and FFT, z-transform. Sampling theorem. Linear Time-Invariant (LTI) Systems: definitions and properties; causality, stability, impulse response, convolution, poles and zeros, parallel and cascade structure, frequency response, group delay, phase delay. Signal transmission through LTI systems. Control Systems: Basic control system components; block diagrammatic description, reduction of block diagrams. Open loop and closed loop (feedback) systems and stability analysis of these systems. Signal flow graphs and their use in determining transfer functions of systems; transient and steady state analysis of LTI control systems and frequency response. Tools and techniques for LTI control system analysis: root loci, Routh-Hurwitz criterion, Bode and Nyquist plots. Control system compensators: elements of lead and lag compensation, elements of Proportional-Integral-Derivative (PID) control. State variable representation and solution of state equation of LTI control systems. Communications: Random signals and noise: probability, random variables, probability density function, autocorrelation, power spectral density. Analog communication systems: amplitude and angle modulation and demodulation systems, spectral analysis of these operations, superheterodyne receivers; elements of hardware, realizations of analog communication systems; signal-to-noise ratio (SNR) calculations for amplitude modulation (AM) and frequency modulation (FM) for low noise conditions. Fundamentals of information theory and channel capacity theorem. Digital communication systems: pulse code modulation (PCM), differential pulse code modulation (DPCM), digital modulation schemes: amplitude, phase and frequency shift keying schemes (ASK, PSK, FSK), matched filter receivers, bandwidth consideration and probability of error calculations for these schemes. Basics of TDMA, FDMA and CDMA and GSM. Electromagnetics: Elements of vector calculus: divergence and curl; Gauss' and Stokes' theorems, Maxwell's equations: differential and integral forms. Wave equation, Poynting vector. Plane waves: propagation through various media; reflection and refraction; phase and group velocity; skin depth. Transmission lines: characteristic impedance; impedance transformation; Smith chart; impedance matching; S parameters, pulse excitation. Waveguides: modes in rectangular waveguides; boundary conditions; cut-off frequencies; dispersion relations. Basics of propagation in dielectric waveguide and optical fibers. Basics of Antennas: Dipole antennas; radiation pattern; antenna gain.
ALL THE BEST FOR GATE PREPARATION
|
10
August
antenna noise temperature
Antenna noise temperature
From Wikipedia, the free encyclopedia
In telecommunication, antenna noise temperature is the temperature of a hypothetical resistor at the input of an ideal noise-free receiver that would generate the same output noise power per unit bandwidth as that at the antenna output at a specified frequency.
Antenna noise temperature has contributions from several sources:
- Galactic radiation
- Earth heating
- The sun
- Electrical devices
- The antenna itself
Galactic noise is high below 1000 MHz. At around 150 MHz, it is approximately 1000K. At 2500 MHz, it has leveled off to around 10K.
Earth has an accepted standard temperature of 290K.
The level of the sun's contribution depends on the solar flux. It is given by
- where
is the solar flux,
is the wavelength,
- and
is the gain of the antenna in decibels.
The antenna noise temperature depends on antenna coupling to all noise sources in its environment as well as on noise generated within the antenna. That is, in a directional antenna, the portion of the noise source that the antenna's main and side lobes intersect contribute proportionally.
For example, a satellite antenna may not receive noise contribution from the earth in its main lobe, but sidelobes will contribute a portion of the 290K earth noise to its overall noise temperature.
ITS MY BE USE FOR U
Wires and connections praneeth kumar 456 | ||
Component | Circuit Symbol | Function of Component |
Wire | To pass current very easily from one part of a circuit to another. | |
Wires joined | A 'blob' should be drawn where wires are connected (joined), but it is sometimes omitted. Wires connected at 'crossroads' should be staggered slightly to form two T-junctions, as shown on the right. | |
Wires not joined | In complex diagrams it is often necessary to draw wires crossing even though they are not connected. I prefer the 'bridge' symbol shown on the right because the simple crossing on the left may be misread as a join where you have forgotten to add a 'blob'! |
Power Supplies praneeth kumar456 | ||
Component | Circuit Symbol | Function of Component |
Cell | Supplies electrical energy. The larger terminal (on the left) is positive (+). A single cell is often called a battery, but strictly a battery is two or more cells joined together. | |
Battery | Supplies electrical energy. A battery is more than one cell. The larger terminal (on the left) is positive (+). | |
DC supply | Supplies electrical energy. DC = Direct Current, always flowing in one direction. | |
AC supply | Supplies electrical energy. AC = Alternating Current, continually changing direction. | |
Fuse | A safety device which will 'blow' (melt) if the current flowing through it exceeds a specified value. | |
Transformer | Two coils of wire linked by an iron core. Transformers are used to step up (increase) and step down (decrease) AC voltages. Energy is transferred between the coils by the magnetic field in the core. There is no electrical connection between the coils. | |
Earth (Ground) |
A connection to earth. For many electronic circuits this is the 0V (zero volts) of the power supply, but for mains electricity and some radio circuits it really means the earth. It is also known as ground. |
Output Devices: Lamps, Heater, Motor, etc. praneeth kumar456 | ||
Component | Circuit Symbol | Function of Component |
Lamp (lighting) | A transducer which converts electrical energy to light. This symbol is used for a lamp providing illumination, for example a car headlamp or torch bulb. | |
Lamp (indicator) | A transducer which converts electrical energy to light. This symbol is used for a lamp which is an indicator, for example a warning light on a car dashboard. | |
Heater | A transducer which converts electrical energy to heat. | |
Motor | A transducer which converts electrical energy to kinetic energy (motion). | |
Bell | A transducer which converts electrical energy to sound. | |
Buzzer | A transducer which converts electrical energy to sound. | |
Inductor (Coil, Solenoid) |
A coil of wire which creates a magnetic field when current passes through it. It may have an iron core inside the coil. It can be used as a transducer converting electrical energy to mechanical energy by pulling on something. |
Switches praneeth kumar 456 | ||
Component | Circuit Symbol | Function of Component |
Push Switch (push-to-make) |
A push switch allows current to flow only when the button is pressed. This is the switch used to operate a doorbell. | |
Push-to-Break Switch | This type of push switch is normally closed (on), it is open (off) only when the button is pressed. | |
On-Off Switch (SPST) |
SPST = Single Pole, Single Throw. An on-off switch allows current to flow only when it is in the closed (on) position. | |
2-way Switch (SPDT) |
SPDT = Single Pole, Double Throw. A 2-way changeover switch directs the flow of current to one of two routes according to its position. Some SPDT switches have a central off position and are described as 'on-off-on'. | |
Dual On-Off Switch (DPST) |
DPST = Double Pole, Single Throw. A dual on-off switch which is often used to switch mains electricity because it can isolate both the live and neutral connections. | |
Reversing Switch (DPDT) |
DPDT = Double Pole, Double Throw. This switch can be wired up as a reversing switch for a motor. Some DPDT switches have a central off position. | |
Relay | An electrically operated switch, for example a 9V battery circuit connected to the
coil can switch a 230V AC mains circuit. NO = Normally Open, COM = Common, NC = Normally Closed. |
Resistors praneeth kumar 456 | ||
Component | Circuit Symbol | Function of Component |
Resistor | A resistor restricts the flow of current,
for example to limit the current passing through an LED.
A resistor is used with a capacitor in a timing circuit.
Some publications still use the old resistor symbol: | |
Variable Resistor (Rheostat) |
This type of variable resistor with 2 contacts (a rheostat) is usually used to control current. Examples include: adjusting lamp brightness, adjusting motor speed, and adjusting the rate of flow of charge into a capacitor in a timing circuit. | |
Variable Resistor (Potentiometer) |
This type of variable resistor with 3 contacts (a potentiometer) is usually used to control voltage. It can be used like this as a transducer converting position (angle of the control spindle) to an electrical signal. | |
Variable Resistor (Preset) |
This type of variable resistor (a preset) is operated with a small screwdriver or similar tool. It is designed to be set when the circuit is made and then left without further adjustment. Presets are cheaper than normal variable resistors so they are often used in projects to reduce the cost. |
Capacitors praneeth kumar 456 | ||
Component | Circuit Symbol | Function of Component |
Capacitor | A capacitor stores electric charge. A capacitor is used with a resistor in a timing circuit. It can also be used as a filter, to block DC signals but pass AC signals. | |
Capacitor, polarised | A capacitor stores electric charge. This type must be connected the correct way round. A capacitor is used with a resistor in a timing circuit. It can also be used as a filter, to block DC signals but pass AC signals. | |
Variable Capacitor | A variable capacitor is used in a radio tuner. | |
Trimmer Capacitor | This type of variable capacitor (a trimmer) is operated with a small screwdriver or similar tool. It is designed to be set when the circuit is made and then left without further adjustment. |
Diodes | ||
Component | Circuit Symbol | Function of Component |
Diode | A device which only allows current to flow in one direction. | |
LED Light Emitting Diode |
A transducer which converts electrical energy to light. | |
Zener Diode | A special diode which is used to maintain a fixed voltage across its terminals. | |
Photodiode | A light-sensitive diode. |
Transistors praneeth kumar 456 | ||
Component | Circuit Symbol | Function of Component |
Transistor NPN | A transistor amplifies current. It can be used with other components to make an amplifier or switching circuit. | |
Transistor PNP | A transistor amplifies current. It can be used with other components to make an amplifier or switching circuit. | |
Phototransistor | A light-sensitive transistor. |
Audio and Radio Devices | ||
Component | Circuit Symbol | Function of Component |
Microphone | A transducer which converts sound to electrical energy. | |
Earphone | A transducer which converts electrical energy to sound. | |
Loudspeaker | A transducer which converts electrical energy to sound. | |
Piezo Transducer | A transducer which converts electrical energy to sound. | |
Amplifier (general symbol) |
An amplifier circuit with one input. Really it is a block diagram symbol because it represents a circuit rather than just one component. | |
Aerial (Antenna) |
A device which is designed to receive or transmit radio signals. It is also known as an antenna. |
Meters and Oscilloscope praneeth kumar 456 | ||
Component | Circuit Symbol | Function of Component |
Voltmeter | A voltmeter is used to measure voltage.
The proper name for voltage is 'potential difference', but most people prefer to say voltage! | |
Ammeter | An ammeter is used to measure current. | |
Galvanometer | A galvanometer is a very sensitive meter which is used to measure tiny currents, usually 1mA or less. | |
Ohmmeter | An ohmmeter is used to measure resistance. Most multimeters have an ohmmeter setting. | |
Oscilloscope | An oscilloscope is used to display the shape of electrical signals and it can be used to measure their voltage and time period. |
Sensors (input devices) praneeth kumar 456 | ||
Component | Circuit Symbol | Function of Component |
LDR | A transducer which converts brightness (light) to resistance (an electrical property).
LDR = Light Dependent Resistor | |
Thermistor | A transducer which converts temperature (heat) to resistance (an electrical property). |
Logic GatesLogic gates process signals which represent true (1, high, +Vs, on) or false (0, low, 0V, off).For more information please see the Logic Gates page. There are two sets of symbols: traditional and IEC (International Electrotechnical Commission). | |||
Gate Type | Traditional Symbol | IEC Symbol | Function of Gate |
NOT | A NOT gate can only have one input. The 'o' on the output means 'not'. The output of a NOT gate is the inverse (opposite) of its input, so the output is true when the input is false. A NOT gate is also called an inverter. | ||
AND | An AND gate can have two or more inputs. The output of an AND gate is true when all its inputs are true. | ||
NAND | A NAND gate can have two or more inputs. The 'o' on the output means 'not' showing that it is a Not AND gate. The output of a NAND gate is true unless all its inputs are true. | ||
OR | An OR gate can have two or more inputs. The output of an OR gate is true when at least one of its inputs is true. | ||
NOR | A NOR gate can have two or more inputs. The 'o' on the output means 'not' showing that it is a Not OR gate. The output of a NOR gate is true when none of its inputs are true. | ||
EX-OR | An EX-OR gate can only have two inputs. The output of an EX-OR gate is true when its inputs are different (one true, one false). | ||
EX-NOR | An EX-NOR gate can only have two inputs. The 'o' on the output means 'not' showing that it is a Not EX-OR gate. The output of an EX-NOR gate is true when its inputs are the same (both true or both false). |
